- Professional-Level Coverage: Designed for mid to large workshops, covering 100+ US, Asian, and European brands with near OE-level diagnostics.
- Online ECU Coding & Programming: Perform ECU coding and cloud-based programming for brands like BMW, Mercedes-Benz, VW/Audi, Porsche, Jaguar/Land Rover, Nissan, Subaru, and Renault—without manufacturer software.
- AutoAuth FCA Gateway Access: Communicate with Chrysler, Dodge, Jeep, Alfa Romeo, and Fiat via FCA SGW authentication.
- System Topology Mapping: View complete vehicle networks and control units for a clear overview of system status.
- Advanced Diagnostic Functions: Includes guided functions, active tests, module replacement, and live data graphing.
- Comprehensive Maintenance Services: 34+ service functions including Oil Reset, EPB, DPF, TPMS, Injector Coding, IMMO, Gear Learning, and more.
- VCI & Protocol Support: Comes with the Phoenix MDCI Pro, supporting J2534, DoIP, CAN FD, D-PDU, and RP1210 protocols.
- Smart Design: Features AutoVIN, camera VINScan, multilingual support, Wi-Fi updates, and modular expansion for ADAS and battery testing.
Ideal for: Workshops needing a high-performance, all-in-one diagnostic and ECU programming solution with continuous updates and broad vehicle compatibility.
Specifications
Hardware & System:
- Display: 10.1-inch LCD, 1280 × 800 resolution
- CPU: Quad-core 2.0GHz processor
- Operating System: Android 10.0
- Memory: 4GB RAM + 128GB ROM
- Battery: 12,000 mAh / 3.8V lithium battery
- Operating Voltage: 9–18V
Environmental Conditions:
- Operating Temperature: 0°C – 50°C (32°F – 122°F)
- Storage Temperature: -20°C – 60°C (-4°F – 140°F)
Physical Parameters:
- Dimensions: 278 × 191 × 48 mm (10.94 × 7.52 × 1.89 in)
- Package Size: 468 × 320 × 143 mm (18.43 × 12.60 × 5.63 in)
- Net Weight: 1455 g (3.20 lb)
Language Support:
English, French, German, Spanish, Portuguese, Russian, Japanese, Italian, Korean, Traditional Chinese, Hungarian, Dutch, Turkish, Polish, Finnish
Smart MDCI Specifications:
- Protocols Supported: J2534, CAN FD, DoIP
- Working Range: 0–30V
Package Includes:
- Phoenix Smart Tablet
- VCI Dongle (J2534)
- OBDI Adapter Box Transfer Line
- OBDII Extension Cable
- Cigarette Lighter Cable
- Type-C to USB Cable
- Battery Clamps/Cable Set
- Power Adaptor
- User Manual
- Password Envelope
- Non-16pin Adaptor Cable Kit
- BMW Programming Line
- Ethernet Cable
- USB Ethernet Adapter
