- OE-Level System Coverage: Exceptional coverage for all electronic systems
- Diagnostics Functions: Read codes, live data, ECU information, and perform active tests, adaptations, and matching
- Service Functions: Expansive 40+ menu of service and maintenance tasks
- Protocols Supported: DoIP and CAN FD
- AutoVIN Technology: Smart AutoVIN for easy vehicle identification
- Updates: Automatic system and software updates with real-time push notifications via the Internet
- Remote Support: Instant remote control technical support anytime, anywhere
- TPMS Diagnostics: Advanced TPMS diagnostics with DTC description and status check
- TPMS Functions: Activate all known TPMS sensors and program AUTEL MX-Sensor
- OBD Relearn: Comprehensive OBD relearn coverage with on-screen relearn procedure
- Workshop Management: One-stop multitasking for efficient management of data files, customer info, and vehicle records
- Reporting: Supports Pre & Post Scan reports
Specifications
- Operating System: Android 11
- Processor: Quad-core 1.8GHz
- Memory: 4GB RAM & 64GB ROM
- Display: 8-inch LCD capacitive touchscreen with 1280×800 resolution
- Rear Camera: 8 MP
- Connectivity: USB Type-C, USB 2.0, Wi-Fi, Bluetooth, Mini SD card (supports up to 64GB)
- Audio Input/Output: Input: N/A, Output: Buzzer
- Battery: 3.7V / 7700mAh lithium-polymer
- Charging: Via 5V DC power supply, Battery Input: 5V/3A
- Operating Temperature: 0–50°C (32–122°F)
- Storage Temperature: -10–60°C (14–140°F)
- Protocols Supported: ISO9141-2, ISO14230-2, ISO15765, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, ISO11898 (High-speed, Middle-speed, Low-speed, Single-wire CAN, Fault-Tolerant CAN), SAE J2610, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP2.0, TP1.6, DoIP, CAN FD
